Oxidized Bitumen – Extreme Specifications & Industrial Uses

Complete specifications chart of all Oxidized Bitumen (Blown Asphalt) grades. Learn their industrial uses, technical data, and how to choose the right grade.

Oxidized Bitumen Technical Specifications

Oxidized Bitumen, also known as Blown Asphalt, is available in a range of grades tailored to specific industrial uses. These grades differ in softening point, penetration value, and viscosity, making each suitable for unique environments such as waterproofing, insulation, road construction, and protective coatings.

This post presents a complete overview of Oxidized Bitumen grades, their technical properties, and applications, ensuring that engineers, procurement teams, and infrastructure planners can select the ideal grade for each use case.

Applications of Bitumen 60/70, Blown Asphalt Production Process, Asphalt road surfaces,
Inquire Now

📊 Oxidized Bitumen Grades – Technical Specification Chart

GradeSoftening Point (°C)Penetration (dmm @25°C)Flash Point (°C)Solubility (%)Ductility (cm)Specific GravityApplication Focus
75/2575 ± 520–30>230≥99<1~1.00Roofing, Damp-proofing, Coatings
75/3075 ± 525–35>230≥99<1~1.00Pipe Coating, Adhesives, Joint Fillers
75/3575 ± 530–40>230≥99<1~1.00Infrastructure Insulation
85/2585 ± 520–30>240≥99<1~1.03Chemical Lining, Industrial Flooring
85/3085 ± 525–35>240≥99<1~1.03Mastics, Roofing Membranes
85/4085 ± 535–45>240≥99<1~1.03Expansion Joints, Static Seals
90/1090 ± 510–20>250≥99<1~1.05Acid/Alkali Tanks, Waterproof Barriers
90/1590 ± 515–25>250≥99<1~1.05Pipe Wrapping, Industrial Sealants
90/4090 ± 530–40>250≥99<1~1.05Joint Fillers, Roof Sheeting
95/2595 ± 520–30>250≥99<1~1.06High-Traffic Zones, Marine Coatings
105/15105 ± 510–20>260≥99<1~1.07Oil Refineries, Tank Coatings
105/35105 ± 530–40>260≥99<1~1.07Expansion Joint Fillers, Rigid Mastic
110/30110 ± 525–35>260≥99<1~1.08Pipe Wraps, Concrete Barriers
115/15115 ± 510–20>270≥99<1~1.08Thermal Coating, Industrial Roofing
150/05150 ± 55–10>280≥99<1~1.10Foundry Mold Coatings, Heat Shields
Inquire Now
Applications of Bitumen 60/70, Penetration Asphalt, Blown Asphalt Production Process, How to Produce Oxidized Bitumen? Industrial Bitumen Uses,

🏭 Industrial Applications of Oxidized Bitumen Grades

Each grade is formulated to match specific thermal resistance, mechanical durability, and chemical stability needs:

🧱 Structural Joint Sealing

Grades like 85/40, 90/40, and 105/35 are ideal for rigid expansion joints in bridges, highways, and industrial flooring where flexibility is minimal and stability under pressure is critical.

🛢️ Steel Pipe and Tank Coating

Grades like 90/15, 95/25, and 110/30 offer outstanding corrosion resistance and waterproofing when applied to steel pipelines, storage tanks, and marine systems.

🧪 Chemical Containment Systems

With low ductility and high flash points, grades such as 90/10 and 105/15 are used in basins, containment areas, and reactors in chemical processing plants.

🏠 Roofing and Insulation Systems

Grades like 75/25, 85/30, and 115/15 serve in multilayer roofing systems to act as durable waterproof membranes resistant to UV and heat.

🧰 Rigid Adhesives and Industrial Mastics

Used in cold-applied and hot-applied adhesive systems, grades like 75/30, 85/30, and 90/40 deliver long-lasting performance in glues, mastics, and filler products.

Inquire Now

📊 Oxidized Bitumen Grades Overview

Click on each Oxidized bitumen grade and read more about that.

Grade Grade Grade Grade
Oxidized Bitumen 75/25Oxidized Bitumen 75/30Oxidized Bitumen 75/35Oxidized Bitumen 85/25
Oxidized Bitumen 85/30Oxidized Bitumen 85/40Oxidized Bitumen 90/10Oxidized Bitumen 90/15
Oxidized Bitumen 90/40Oxidized Bitumen 95/25Oxidized Bitumen 95/35Oxidized Bitumen 100/15
Oxidized Bitumen 105/15Oxidized Bitumen 105/35Oxidized Bitumen 110/30Oxidized Bitumen 115/15
Oxidized Bitumen 115/35Oxidized Bitumen 120/25Oxidized Bitumen 120/35Oxidized Bitumen 150/05

PEAK UNIVERSAL BUSINESS LTD.  as Your trusted Supplier & Partner in high-performance bitumen solutions.

FAQs about Oxidized Bitumen Grades

What is the main difference between oxidized and penetration bitumen?

Penetration bitumen is softer and temperature-sensitive, while blown asphalt has been air-blown to enhance hardness, aging resistance, and thermal stability.

How is oxidized bitumen applied in waterproofing?

It is melted and applied as a liquid sealant in layers. Upon cooling, it hardens into a waterproof, chemically-resistant layer for foundations, tunnels, and rooftops.

Which grade is best for expansion joints?

Grades such as 90/40, 105/35, and 110/30 are best due to their hardness, low ductility, and resistance to temperature fluctuations.

Is oxidized bitumen environmentally safe?

Yes, when used properly. It is inert, non-volatile, and has minimal leaching, making it suitable for sealed applications in construction and industry.

Can oxidized bitumen be blended with solvents or polymers?

Yes, with ≥99% solubility in TCE, it is compatible with a wide range of solvents, and can also be modified with SBS/APP polymers for enhanced flexibility.

Inquire Now

🔍 Conclusion- Oxidized Bitumen Technical Specifications

Oxidized Bitumen offers unmatched performance for industrial-scale waterproofing, insulation, sealing, and protective coatings. With a variety of grades tailored to specific temperature, pressure, and chemical conditions, it remains a top choice for engineers and contractors worldwide.

Whether you’re dealing with expansion joints, roof membranes, or chemical basins, choosing the right bitumen grade ensures long-term durability, safety, and compliance.
