Viscosity Grade Bitumen

Viscosity grading can be done on original (as-supplied) asphalt binder samples (called AC grading) or aged residue samples (called AR grading). The AR viscosity test is based on the viscosity of aged residue from the rolling thin film oven test.

Product Overview

Peak Universal Business , your premier destination for high quality Viscosity Grade Bitumen solutions. Viscosity Grade Bitumen is a crucial component in road construction and infrastructure projects, offering superior performance and durability in various weather conditions.

Our Viscosity Bitumen range includes AC Grade , AR Grade & VG Grade. Each grade is meticulously engineered to meet specific viscosity requirements, ensuring optimal performance and longevity for different applications.

At Peak Universal Business, we prioritize quality and consistency in our Viscosity Grade Bitumen products . Our bitumen is manufactured to comply with industry standards and undergoes stringent quality control measures to guarantee reliability and performance excellence.

Trust Peak Universal Business as your dependable supplier for premium Viscosity Grade Bitumen .

Click Below to explore different types of Viscosity Bitumen we offer:

Inquire Now
Viscosity Bitumen

Viscocity grade over penetration grade several key issues are addressed, like:

  • Performance at high temperatures by adopting a viscosity-graded bitumen specification (based on viscocity at 60 °C), in place of the current penetration-graded specification (based on penetration at 25 °C)
  • Issues relating to compaction, which the tender asphalt mixtures create as push and shove under the roller wheels, have also addressed by having a requirement of minimum viscosity at 135°C, it will be helpful in minimizing the tender mix problems in the field.
  • Adoption of viscosity-graded paving bitumen specifications will also reduce the number of total tests to 7 Without compromising the quality of bitumen and also no new tests are required in implementing this specification.

Viscosity grades Bitumen are categorized according to Viscosity (degree of fluidity) grading.

The higher the grade, the stiffer the Bitumen. In Viscosity Grade, Viscosity tests are conducted at 60°C and 135°C, which represents the temperature of road surface during summer and mixing temperature respectively.

The penetration at 25°C, which is annual average pavement temperature, has been also retained in Specifications.

Main Uses of VG Bitumen

  1. Roads & highways – durable binder for flexible pavements.

  2. Airport runways – stability under heavy traffic and high temperatures.

  3. Industrial pavements & floors – withstands stress and load.

  4. Waterproofing & roofing – protects structures against water penetration.

  5. Asphalt mixes & sealants – ensures long service life.

Viscosity Grade Bitumen Specification (ASTM D3381-09)

Property Units AC-10 AC-20 AC-30 AC-40 Test Methods
Viscosity, 140°F (60°C) P 1000±200 2000±400 3000±600 4000±800 ASTM D-2171
Viscosity, 275°F (135°C), Min cSt 150 210 250 300 ASTM D-2171
Penetration, 77°F (25°C), 100g, 5sec, Min 0.1MM 70 40 30 20 ASTM D-5
Flash point, Cleveland open cup, Min °C 219 232 232 232 ASTM D-92
Solubility in trichloroethylene, Min %Wt 99 99 99 99 ASTM D-2042

Tests on residue from thin-film oven test:
  – Viscosity, 140°F (60°C), Max P 5,000 10,000 15,000 20,000 ASTM D-2171
  – Ductility, 77°F (25°C), 5cm/min, Min CM 50 20 15 10 ASTM D-113
